| POWER REQUIREMENT |
| Power supply |
12VDC Optional: 9VDC Battery (approximately 1 year operation if running on battery only) |
| Idle Operation current |
≤10µA |
| Alarm trigger current |
20 ~ 50 mA |
| SENSOR DETAILS |
| Size |
110mm X 25mm |
| Smoke Sensitivity |
Complies with UL217 & BS5446: Part 1 2000 |
| Photoelectric sensor |
Yes |
| Heat to trigger alarm |
Adjustable, up to 58°C |
| Alarm indication |
Red LED and Sounder |
| Alarm sound |
85 Decibels at 10 feet |
| Operating temperature |
4.4C to 37.8°C |
| Operating humidity |
10 ~ 90% |
|
