| SPECIFICATIONS |
| The Panel & Frame |
• Dimension (mm) |
160 x 960 x 51 |
| • Thickness (mm) |
50 |
| • Build Up Material |
Extruded aluminium PVC back cover & corner |
| • Color |
Chrome & black |
| The Power & Consumption |
• Power Supply |
230VDC +/- 10% 56/60Hz |
| • Power Consumption |
10W without load, 200W Max load (8 panels), 400W Max load (16 panels) |
| • Max Watts Per Pixel (W) |
0.08 |
| • Display Color |
Red |
| • Brightness levels |
Up to 15 levels |
The Installation & Working Environment
The Performance |
• Operating Temperature (°C) |
0 ~ 40 |
| • Storage Temperature (°C) |
0 ~ 60 |
| • Relative Humidity |
< 95% non-condensing |
| • Module Matrix |
16 (H) x 32 (W) |
| • Character Row Pitch (mm) |
10 |
| • Column Pitch (mm) |
10 |
| • Horizontal Viewing Angle |
160 |
| • LED Diode Life |
Estimated 100,000 hours |
| • Communication Interface |
RS 232/USB/Wireless/LAN |
| • Cable Length |
Power cable – 3 m, USB cable – 4 m |
| • Memory Retention |
Approximate 3 months |
