| Express Setup |
| Quick Setup Wizard to facilitate simple
configuration during initial startup |
| Automatically defines all necessary system
components |
| Innovative features reduce time required to
configure the system and eliminates
programming errors |
| Enhanced Software Security Features |
| Optional fingerprint login for system
administrators |
| Screen-lock function; automatic logout after
timeout period |
| Full backup and restoral of system data |
| Detailed history records and audit trail
functions for tracking past configuration
changes |
| Access Control Reports |
| 14 types of listing & event reports |
| Comprehensive event filtering |
| Quick-print and email action |
| Supports digital watermark imprint |
| Reports can be exported into 10 formats
e.g: .xls, .txt, .csv |
| Easy Time Scheduling |
| Provides up to 3 time zone settings per day |
| Allows time-based access permission to be
defined per weekday |
| Provides holiday configuration & holiday
time zone settings |
| User-Friendly Interface |
| Change views, reorder columns, and modify
& filter data for groups of users from a single
screen |
| Different user interface themes available for
preference |
| Simple-to-understand organization with
Windows “tree structure” design, complete
with ribbon-style menu layouts |
| Full Duplex Synchronization |
| Fully synchronize data between device and
database |
| Easily synchronize data to device after
changes are made |
Selectable single record or multiple records
to be synchronized |
| Event Priority & Alerts |
| Organize alarm alerts and set alarm
priorities to optimize response time |
| Configure event priorities from a total of 62
event types |
| Offline door events, alarm events & terminal
connection events |
| Automatically sends email and notifications
to defined recipients when an event is
detected in the system |
| Customizable sound alerts for every priority |
| PUSH notifications are available for iOS and
Android device users |
| Effortless Device Replacement |
| Backup device and door settings or
configuration |
| Easily transfer settings to new replacement
device |
|
|
| Efficient Management of Users |
| Supports 10 levels of departments |
| Track users card management records and
history |
| Detailed permissions and user rights for the
access, display and control of subsystems |
| Integration with OFIS-x and OFIS-y for
fingerprint registration station |
| Powerful Access Control Settings |
| Interlocking |
| Anti-passback |
| Multi-card operation |
| Fire alarm linkage |
| Multiple verification setting |
| Door-always-open schedule |
| Integrated Monitoring |
| Real-time alarm or event logs to ensure all
events are completely documented (including messages and controls) for the
entire system |
| Remotely control door access, including
unlocking doors and disarming alarms |
| Display up to a maximum of 9 floor maps for
real-time monitoring |
| Graphic map display with animated icons for
instant visibility of activity |
| Multiple workstation monitoring capabilities |
| Time Attendance Functions |
| Weekly schedules available with 3 pairs of
IN/OUT columns for attendance monitoring |
| Supports group or personal duty roster setup |
| Supports leave and holiday management |
| Generate attendance sheets, and instantly
add, edit, or delete attendance records |
| Provides 15 types of commonly used time
attendance reports, eg: daily attendance
listing, tardiness report, and on-leave listing. |
| Terminal data audit list enables raw data
checking and export |
| Simple export for attendance data using the
configurable export template format |
| Post attendance data to SAGE UBS payroll
easily |
| Timer feature for automatic download of data
after a specified interval |
| Support up to 9 digits of workcodes |
| Additional Features |
| Supports multiple languages |
| Add users by batch |
| Automatic search of devices over the network |
| Multiple views for event monitoring |
| Intelligently import users from 3rd party
software |
| Easy data grouping or filtering for viewing
purposes |
| Integrated with IPC Video
Surveillance SoftwareFeatures |
| Integrated with Milestone’s XProtect series
and EpiCamera’s cloud storage solution |
| Users can quickly track or playback captured
video clips or pictures of the door event |
| Supports live feed directly from the IP camera |
| The Play Video Window supports frame
selection, variable speed, pause and export to
AVI and JPG files |
|
|
|
| |
| Operating system: Window XP, Window Vista, Window 7,
Window 8, Server 2003/2008 (32 or 64-bit) |
|
Operating system: Window XP, Window Vista, Window 7, Window 8,
Server 2003 / 2008 (32 or 64-bit) |
| Processor: Intel® Core® 2 Duo 2.5 GHz or higher |
|
Processor: Intel® Core® 2 Duo 2.0 GHz or higher |
| Memory: 3 GB of RAM or higher |
|
Memory: 2 GB of RAM or higher |
| Hard drive: 80 GB |
|
Hard drive: 50 GB |
| Resolution: 1024 x 768 or higher |
|
Resolution: 1366 x 768 or higher |
|
|
|
|
| Description |
Ingressus I |
Ingressus II |
Ingressus IV |
| Basic |
|
|
|
| Dimension (L X W X H), mm |
186 x 106 x 36 |
226 x 106 x 36 |
| Power input |
|
12V DC |
|
| Operating temperature (°C) |
|
0 - 55 |
|
| Operating humidity (%) |
|
10 - 80 |
|
| CPU |
|
32-bit, 400MHz |
|
| Flash memory (MB) |
|
128 |
|
| SDRAM (MB) |
|
32 |
|
| Polarity protection |
|
Yes |
|
| Storage |
|
|
|
| Fingerprints |
|
3000 |
|
| Cards |
|
30000 |
|
| Passwords |
|
30000 |
|
| Transactions |
|
100000 |
|
| Communications |
|
|
|
| Communications with server |
|
TCP/IP, RS485 |
|
| Quantity of terminal |
2 |
4 |
2 |
Communication with
terminals |
2 x 26-bit Wiegand
input. Each for 1 slave
terminal (1 x RS485
input to support
RS485 network)
(max 2 units) |
4 x 26-bit Wiegand
input. Each for 1 slave
terminal (1 x RS485
input to support
RS 485 network)
(max 4 units) |
4 x 26-bit Wiegand
input. Each for 1 slave
terminal (1 x RS485
input to support
RS 485 network)
(max 8 units) |
| Input |
|
|
|
| Push release button |
1 |
2 |
4 |
| Door sensor |
1 |
2 |
4 |
| AUX |
1 |
2 |
4 |
| Types of AUX input supported |
Motion detector, passive DIR detector, curtain passive infrared
detector, pet immunity PIR detector,
two beam digital active infrared detector, heat detector |
| Output |
|
|
|
| Door lock (12VDC 10A form C relay) |
1 |
2 |
4 |
| AUX output (30VDC 2A form C relay) |
1 |
2 |
4 |
| Types of AUX output supported |
Gas detector and compatible sensors, Piezo strobe siren,
electronic siren |
| Access control features |
|
|
|
| Main Features |
Door opening time (0-999s), Inter-locking (lnggressus II & IV only),
Anti-pass back (Local only), Multi card unlocking, First card unlocking, Time zone (50), Holiday time zone, Permanent door release/ lock time zone, Day light saving time zone,
Continuous verification of users |
| Security Features |
Door force open alarm, Door open time out alarm,
Fire linkage, Duress alarm,
Door status and event (51 types) |
| SOFTWARE |
|
|
|
| Ingress |
|
Bundled |
|
|
FEATURES
