No Worries About Lost Keys
In case you lose your house keys, you don’t need to worry about the possibility of intruders because your house will be protected with the H2i and you can enter the house using your fingerprint. The H2i is also suitable when you go for an exercise session or take a quick stroll outdoors - you won’t need to worry about forgetting to lock the door, as the electromagnetic lock will auto-lock the door.
No Risk of H2i Tampering
With the complete package, tampering with the H2i will not compromise the door because the H2i Home Package comes with the latest AdapTec Plus, which is a controller stored away and out of sight from the H2i terminal. The lock will only be released once it receives a verification signal from the terminal and any attempt to tamper with the terminal will not affect the lock at all!

Enhanced Home Security with Biometrics Technology
Fingerprint technology is the sought-after commercial access technology in the world today and with one touch of your finger, you can confirm true identity in seconds.
Keep the Existing Lock
There is no need to change your house’s existing lock – install the H2i as an extra protection that goes along with convenience with the use of fingerprints!

Easy Data Management
All you need is a USB flash disk to transfer transaction logs to your computer. It is that easy!
Be Secure with Style
Who says you can’t be stylish? The simple and sleek design of the H2i looks good in any setting of a workplace!

Link It to An Alarm System
For extra protection, link the H2i to the readily available siren embedded in the AdapTec Plus or you can link it straight to your third party alarm system; either way, the H2i is designed to protect your family.
Simple Installation & Operation
H2i Home Package includes all the required accessories for a complete installation and any qualified installer or technician can get it done in no time! And you don’t need to be tech-savvy to use H2i, as the operation is voice-guided and a user guide DVD is provided for extra convenience.

Get More Verification Options
Get 5 extra cards with each H2i and this can be a verification option suitable for family members and house guests.
Cost Effective
The H2i is clearly a simple and economical biometric access control solution, which has just the qualities you need in your home security system!

INSTALLATION DIAGRAM
for illustration only
Specifications
SURFACE FINISHING Acrylonitrile Butadiene Styrene (ABS)
TYPE OF SCANNER Optical
PROCESSOR 300 MHz microprocessor
MEMORY 32MB flash memory
ALGORITHM BioBridge VX 10.0 (optional VX 9.0)
PRODUCT DIMENSION (L X W X H), mm 78 x 50 x 150
STORAGE
• Fingerprint templates 1500
• Transaction 100000
ENROLLMENT & VERIFICATION
• Methods Fingerprint, Card
• Recommended fingerprint per user ID 2
• Fingerprint placement Any angle
• Verification time (sec) < 1
• FAR (%) < 0.0001
• FRR (%) < 1
CARD TECHNOLOGY
• RFID: 64-bit, 125kHz Yes
COMMUNICATIONS
• Method TCP/IP, RS485, USB flash disk
• Baud rates 9600, 19200, 38400, 57600, 115200
• Wiegand 26-bit input/output
OPERATING ENVIRONMENT
• Temperature (°C) 0 ~ 45
• Humidity (%) 20 ~ 80
• Power input DC 12V 3A
MULTIMEDIA
• Voice Yes
ACCESS CONTROL
• EM lock driving output DC 12V 3A / Relay output
• Alarm output NO / NC
• Antipassback Yes
VOICE LANGUAGE (TERMINAL) English (Default) | Other languages are available upon request.
SOFTWARE FingerTec Data Processor (FTDP)

RECOMMENDED ACCESSORIES
http://info.fingertec.com/h2i-9
• EM- Lock 600 lbs/ Drop Bolt/ Door Strike     • AdapTec Plus     • Rechargeable Backup Battery     • Contactless Release Button     • DIY Metal Casing     • Emergency Break Glass • Key Switch
Top Quality Hardware
FingerTec hardware is FCC and CE certified, and goes through thorough and discreet QC procedures.
End-User Support Site
Get FingerTec’s various online resources and support at http://user.fingertec.com.
TCMS V2 Software
Get the FREE software that lets you configure and gives you full control over the H2i.
Email and Online Support
Need assistance? Simply drop an email to us at support@fingertec.com or chat live with us via our various online social chats (MSN, Skype etc.)
Global Product Warranty
Get 24months limited warranty on FingerTec products, no matter where you are.
Language Localization
FingerTec’s hardware and software both come in a variety of localized languages for you to pick from.

Packaging
Dimension (mm): 158(L) x 67(W) x 210(H)
Weight: 0.7kg
