Small, Yet Loaded with Capacity
The Kadex and m-Kadex can store a whopping total of 30000 users, and 50000 transaction logs.
Value for Money
Mix and match your FingerTec system with m-Kadex to give you more value for your money. Choose Kadex for the main entrance, m-Kadex for other entrances and i-Kadex for exits. Haven’t you want options in life?

Combine Your Verification Methods
Opt for the combination of verification methods secure your workplace further. Choose the card and password verification with the Kadex for tighter security.
Manage Your Shift Workers
The Kadex and m-Kadex can be programmed with a total of 50 time zones – perfect for companies with shift work.

Manage Your Data Easily
Administration is easy with the Ingress software application. Ingress allows you to remotely manage door activity of all connected terminals, while containing time attendance functions for attendance monitoring.
Built-In Alarm
Increase the security at your workplace by installing an external alarm, and be alerted during unexpected scenarios such as break-ins and fire emergencies.

Simple Administrator Management & Enrollment
The m-Kadex’s simple outlook is complimented with a simple management system. Just swipe your administrator card to enroll, delete, or reset the terminal.
Easy Data Management
All you need is a USB flash disk to transfer transaction logs to your computer. It is that easy!

LAYOUT PLAN
System Communication
for illustration only

Installation Diagram
for illustration only, *AdapTec is sold separately
Specifications
MODEL Kadex m-Kadex i-Kadex
SURFACE FINISHING Akrilonitril Butadiena
Stiren (ABS)
Polikarbonat
TYPE OF SCANNER RFID antenna
PROCESSOR 400 MHz microprocessor FingerTec / Card capturing station
MEMORY 8MB flash memory and 32MB SDRAM
ALGORITHM BioBridge Vx9.0
PRODUCT DIMENSION (L X W X H), mm 92 x 49 x 137 92 x 29 x 134 55 x 15 x 100
STORAGE
• Cards 30000 Storage in master
• Transaction 50000
ENROLLMENTS & VERIFICATION
• Methods Card or Password Card only Card capturing station
• Card per user ID 1
• Reading distance, mm 50 ~ 80
• Verification time (sec) RFID : < 1
MiFARE: < 4
Manage by master
CARD TECHNOLOGY
• RFID: 64-bit, 125kHz Yes
• MIFARE: MFIS50/S70, 13.56MHz Made to order
• HID: HID 1325, 26-bit, 125kHz Made to order N/A
COMMUNICATIONS
• Method TCP/IP, RS232, RS485, USB flash disk Wiegand 26-bit Output
• Baud rates 9600, 19200, 38400, 57600, 115200 TDD
• Wiegand 26-bit input/ output 26-bit output
OPERATING ENVIRONMENT
• Temperature (°C) 0 ~ 45 -10 ~ 70
• Humidity (%) 20 ~ 80
• Power input DC 12V 3A DC 12V 1A
• IP 65 rating No Yes
TIME ATTENDANCE
• Work codes Yes N/A
MULTIMEDIA
• Voice Yes N/A
• Short messaging Ya N/A
ACCESS CONTROL
• EM lock driving output DC 12V 3A Manage by master
• Alarm output NO/NC
• Antipassback Yes
VOICE / DISPLAY LANGUAGE (TERMINAL) (only for Kadex) English (Standard), Arabic, Malay, Indonesian, Chinese (Traditional), Chinese (Simplified), Cantonese, Thai, Vietnamese, Korean, Spanish, Portuguese (Portugal), Portuguese (Brazil), Polish, French, Russian, German, Italian, Turkish, Persian, Slovak, Greek, Dutch, Hebrew, Romanian, Bulgarian. Other languages are available upon request.
NOTE: Specifications are subject to change. Check for latest product information
*N/A: Not applicable
Packaging
1. Kadex
Dimension (mm): 225(L) x 72(W) x 168(H)
Weight: 0.75kg

2. Kadex & i-Kadex
Dimension (mm): 225(L) x 72(W) x 168(H)
Weight: 0.85kg

3. mKadex
Dimension (mm): 225(L) x 72(W) x 168(H)
Weight: 0.75kg

4. m-Kadex & i-Kadex
Dimension (mm): 225(L) x 72(W) x 168(H)
Weight: 0.85kg

5. i-Kadex
Dimension (mm): 173(L) x 60(W) x 135(H)
Weight: 0.26kg
