| SPECIFICATIONS |
 |
• Surface Finishing |
ABS |
| • Operating Power Input |
12 ~ 15VDC 1.2A |
| • Siren Operating Consumption |
12VDC 220mA |
| • Strobe Light Operating Consumption |
12VDC 180mA |
| • Size(mm) |
265 x 170 x 65 |
| • Weight (kg) |
0.65 |
| • Siren Volume |
120±3db@1m |
| • Strobe Light Flash Rate |
≥ 70 times/min |
| • Tamper Protection |
2 |
| • IP Rating |
IP-54 |
| • Backup Battery |
12v1.2A sealed lead battery |
| • Certificate |
CE, EMC |
 |
• Surface Finishing |
ABS Type |
| • Dimension (lxwxh) |
27 mm x 8 mm x 15 mm |
| • Material |
ABS body. Rhodium over gold reeds |
| • Max Contact Rating |
28VDC, 0.5A, 10W |
| • Gap Distance |
25mm |
| • Installation |
Adhesive tape or screw mount |
