A Variety of Verification Methods
Although it’s recommended that you use fingerprint verification for more authentic attendance and access control functions, the terminal also offers options for you to verify using a card or password, or even a combination of the two!. |
|
 |
Precise Recognition
The R2 uses minutiae matching technology that ensures only enrolled users are granted access. |
|
| |
|
 |
Complete Access Solution
Get the R2i slave exit reader to compliment your R2 access control terminal for a full door-in door-out solution! |
|
 |
Easy Data Management
All you need is a USB flash disk to transfer transaction logs to your computer. It is that easy! |
|
| |
|
 |
Manage Your Data Easily
Administration is easy with the bundled software! FingerTec’s TCMS software allows you to generate reports, monitor attendance and integrate FingerTec with a third party system. |
|
 |
Built-In Alarm
Increase the security at your workplace by installing an external alarm, and be alerted during unexpected scenarios such as break-ins and fire emergencies. |
|
| |
|
 |
Short Message Display
Alert your staff by personalizing a short message to be displayed at the terminal when they verify. |
|
 |
Workcodes
Let your staff experience more independence by reporting their whereabouts via our workcodes feature. |
|
|
| |
| Layout Plan |
| System Communication |
| for illustration only |
 |
| |
| Installation Diagram |
| for illustration only |
 |
| |
| Specifications |
| MODEL |
R2 |
R2i |
| SURFACE FINISHING |
Acrylonitrile Butadiene Styrene (ABS) |
| TYPE OF SCANNER |
Optical |
| PROCESSOR |
400 MHz microprocessor |
Fingerprint/ Card capturing station |
| MEMORY |
8MB Flash Memory |
| ALGORITHM |
BioBridge VX 9.0 |
| PRODUCT DIMENSION (L X W X H), mm |
94 x 50 x 189 |
64 x 42 x 135 |
| STORAGE |
| • Fingerprint templates |
3000 |
Storage in master terminal |
| • Transaction |
120000 |
| ENROLLMENT & VERIFICATION |
| • Methods |
Fingerprint (1:1, 1:N), Card & Password |
Fingerprint (1:1, 1:N) & Card |
| • Recommended Fingerprint per user ID |
2 |
N/A |
| • Fingerprint placement |
Any angle |
| • Verification time (sec) |
< 1 |
Manage by master |
| • FAR (%) |
< 0.0001 |
| • FRR |
< 1 |
| CARD TECHNOLOGY |
| • RFID: 64-bit, 125kHz |
Yes |
| • MIFARE: MFIS50/S70, 13.56MHz |
Made to order |
| • HID: HID 1325, 26-bit, 125kHz |
Made to order |
| COMMUNICATIONS |
| • Method |
TCP/IP, RS232, RS485, USB flash disk |
Communicate directly with master reader |
| • Baud rates |
9600, 19200, 38400, 57600, 115200 |
N/A |
| • Wiegand |
26-bit input/output |
N/A |
| OPERATING ENVIRONMENT |
| • Temperature (°C) |
0 ~ 45 |
| • Humidity (%) |
20 ~ 80 |
| • Power input |
DC 12V 3A |
DC 12V 1A |
| TIME ATTENDANCE |
| • Work codes |
Yes |
N/A |
| MULTIMEDIA |
| • Greeting voice |
Yes |
N/A |
| • Short messaging |
Yes |
N/A |
| ACCESS CONTROL |
| • EM lock driving output |
DC12V 3A / Relay output |
Manage by master |
| • Alarm output |
NO/NC |
| • Antipassback |
Yes |
| VOICE / DISPLAY LANGUAGE (TERMINAL) |
English (Standard) / Other languages are available upon request. |
N/A |
| SOFTWARE LANGUAGE |
English, Arabic, Malay, Indonesian, Chinese (Traditional), Chinese (Simplified), Thai, Spanish, Portuguese (Brazil), Polish, Vietnamese, French, Russian, Persian, German, Italian, Turkish |
|
| *N/A: Not applicable |
 |
Packaging
1. R2
Dimension (mm): 245(L) x 90(W) x 225(H)
Weight: 2.3 kg (with AdapTec Plus), 1.24 kg (without AdapTec Plus)
2. R2 & R2i
Dimension (mm): 245(L) x 90(W) x 225(H)
Weight: 1.4kg
3. R2i
Dimension (mm): 80(L) x 50(W) x 200(H)
Weight: 0.2kg |
|
|
|
|
