Increase Your Brand Awareness!
Display a welcoming message or even a trademark logo in a form of a picture(s) on the i-Kiosk 100. We give you branding opportunities at no cost!
Shortcut Keys
Program these keys to take you to commonly used functions in just one step. Did we mention that we make things easy?

Eliminate Buddy Punching
The weakness with the clock-in card system is that ‘buddy punching’ can occur where one employee can clock in the time for another employee if any of them are late. Eliminate this occurrence by using the unique perindividual fingerprint as a clock-in card!

Full Colour Screen
This model comes with a full colour TFT screen. Display pictures corporate advertisements, screen savers and much more on the colour screen of the terminals.




Ease is the Word
With a T9 typing input method and a USB flashdisk port for data transfer, the i-Kiosk 100 could not be any easier for you.
We Offer Variety
Although we do recommend fingerprint verification to eliminate buddy punching, the i-Kiosk 100 also has card and password verification options.
Supersized Capacity
Get up to 10,000 fingerprint templates and 200,000 transaction logs – more than enough to fulfill the requirements of an SME.
Be Warned!
Get even tighter security! With the i-Kiosk 100, you can connect your terminal to an external alarm system to warn against break ins and emergencies

LAYOUT PLAN
System Communication
for illustration only
Installation Diagram
for illustration only
Specifications
MODEL i-Kiosk 100
SURFACE FINISHING Acrylonitrile Butadiene Styrene (ABS)
TYPE OF SCANNER Optical
PROCESSOR 400 MHz microprocessor
MEMORY 256MB flash memory
ALGORITHM BioBridge VX 9.0 / VX 10.0
PRODUCT DIMENSION (L X W X H), mm 166 x 60 x 178
STORAGE
• Fingerprint templates 10000
• Transaction 200000
ENROLLMENT & VERIFICATION
• Methods Fingerprint (1:1, 1:N), Password & Card
• Recommended fingerprint per user ID 2
• Fingerprint placement Any angle
• Verification time (sec) < 1
• FAR (%) < 0.0001
• FRR (%) < 1
CARD TECHNOLOGY
• RFID: 64-bit, 125kHz Yes
• MIFARE: MFIS50/S70, 13.56MHz Made to order
• HID: HID 1325, 26-bit, 125kHz Made to order
COMMUNICATIONS
• Method TCP/IP, RS232, RS485, USB flash disk (Optional WiFi)
• Baud rates 9600, 19200, 38400, 57600, 115200
• Wiegand 26-bit input/output
OPERATING ENVIRONMENT
• Temperature (•C) 0 ~ 45
• Humidity (%) 20 ~ 80
• Power input DC 12V 3A
TIME ATTENDANCE
• Siren Built- in (Optional- External)
• Work codes Yes
MULTIMEDIA
• Voice Yes
• Display 3.5.65k color TFT screen
• Short messaging Yes
ACCESS CONTROL
• EM lock driving output DC 12V 3A / Relay output
• Alarm output NO / NC
• Antipassback Yes
VOICE / DISPLAY LANGUAGE (TERMINAL) English (Standard), Arabic, Malay, Indonesian, Chinese (Traditional), Chinese (Simplified), Cantonese, Thai, Spanish, Portuguese (Portugal), Portuguese (Brazil), French, Russian, German, Italian, Turkish, Persian. Other languages are available upon request.
SOFTWARE LANGUAGE English, Arabic, Arabic (Kuwait), Malay, Indonesian, Chinese (Traditional), Chinese (Simplified), Thai, Vietnamese, Korean, Spanish, Portuguese (Portugal), Portuguese (Brazil), Polish, French, Russian, German, Italian, Turkish, Persian, Lithuanian

Packaging
Dimension (mm): : 245 (L) x 90 (W) x 225 (H)
Weight: : 1.6 kg
