| SURFACE FINISHING |
Acrylonitrile Butadiene Styrene (ABS) & Acrylic |
Acrylonitrile Butadiene Styrene (ABS) & Acrylic |
| TYPE OF SCANNER |
High resolution infrared camera & Card Scanner |
High resolution infrared camera, Optical fingerprint scanner & Card Scanner |
| PROCESSOR |
800 MHz microprocessor |
800 MHz microprocessor |
| MEMORY |
256MB Flash Memory & 64MB SDRAM |
256MB Flash Memory & 64MB SDRAM |
| ALGORITHM |
BioBridge Face VX6.0 |
BioBridge Face VX6.0, Fingerprint BioBridge VX 10.0 |
| DIMENSION (L X W X H), mm |
86 x 62 x 218 |
207 x 120 x 145 |
| STORAGE |
|
|
| • Fingerprint templates |
N/A |
10000 |
| • Face templates |
400 |
500 |
| • Card |
10000 |
10000 |
| • Transaction |
100000 |
200000 |
| ENROLLMENT & VERIFICATION |
|
|
| • Methods |
Face, card or password |
Face, fingerprint, card or password |
| • Recommended fingerprint per user ID |
N/A |
2 |
| • Fingerprint placement |
N/A |
Any angle |
| • Verification time – Face, sec |
< 1 |
< 1 |
| • Verification time – Fingerprint, sec |
N/A |
< 1 |
| • Fingerprint |
N/A |
FAR < 0.0001%, FRR < 0.1% |
| • Face |
FAR < 0.01%, FRR < 0.1% |
FAR < 0.01%, FRR < 0.1% |
| CARD TECHNOLOGY |
|
|
| • RFID: 64-bit, 125kHz |
Yes |
Yes (RF output power (EN300-330)) |
| • MIFARE: MFIS50/S70, 13.56MHz |
Made to order |
Made to order |
| • HID: HID 1325, 26-bit, 125kHz |
Made to order |
Made to order |
| COMMUNICATIONS |
|
|
| • Method |
TCP/IP, RS232, RS485, USB flash disk |
TCP/IP, RS232, RS485, USB flash disk
( Optional - GPRS, WiFi) |
| • Baud rates |
9600 ~ 115200 |
19200 ~ 57600 |
| • Wiegand |
26-bit input and output |
26-bit output |
| OPERATING ENVIRONMENT |
|
|
| • Temperature (°C) |
0 ~ 45 |
0 ~ 45 |
| • Humidity (%) |
20 ~ 80 |
20 ~ 80 |
| • Power input |
DC12V 3A |
DC12V 3A |
| TIME ATTENDANCE |
|
|
| • Siren |
Internal |
Built-in and External |
| • Work codes |
Yes |
Yes |
| • Fast transaction checking |
Yes |
Yes |
| • Receipt printing |
Yes (via RS232) |
N/A |
| MULTIMEDIA |
|
|
| • Greeting voice |
Yes |
Yes |
| • Display |
3.0” 65K color TFT Touch Screen Panel |
4.3” 65K color TFT Touch Screen Panel |
| • Photo-ID |
Yes |
Yes |
| • Short messaging |
Yes |
Yes |
| • Day Light Saving Timer |
Yes |
Yes |
| • Internal Backup Battery |
N/A |
Yes (DC12V, 2000mAh) |
| ACCESS CONTROL |
|
|
| • EM-Lock Driving Output |
DC 12V / Relay output |
DC 12V / Relay output |
| • Alarm output |
NO only |
NO / NC |
| • Antipassback |
Yes |
N/A |
| SOFTWARE |
TCMS V2 |
TCMS V2 |
